Smart Spraying
High-pressure spraying for deep penetration,Capable of both pesticide spraying and seeding or fertilizing.
Quick-Swap Tank
Quick-Release Payload System Effortlessly swap tanks in seconds to maximize your operational efficiency.
Ground Station Control
Intuitive remote piloting with live telemetry, keeping you in complete command from the ground.
IP65 Protection
Fully sealed core components. Highly resistant to dust, water, and harsh agricultural chemicals.
Precision GPS
Pinpoint accuracy for perfectly mapped flight routes and reliable navigation.
Radar Avoidance
Ensure safe operation with front and rear obstacle avoidance radars, and terrain-following radar
Max. Flow Rate
8 L/min
Droplet Size Range
60-400 μm
Spray Width
5-8 m
Operate Efficiency
6.6 ha/h
Grain Crops
Widely used for cereals like rice, wheat, maize, and barley in Asia and Europe.
Commercial Crops
Including cotton, coffee, rubber, and soybeans in South America and Africa.
Fruit Trees
Such as apples, grapes, cherries, and citrus fruits in Europe, North America, and Oceania.
Advanced Core Technologies
Engineered for precision, heavy-duty reliability, and maximum operational efficiency in any agricultural environment.
Flight Control System
The brain of your operation. Our upgraded smart flight controller ensures ultra-stable navigation, precise route execution, and highly responsive handling. Designed specifically for agricultural mapping, it guarantees flawless automation even in complex terrains.
High-Performance Propulsion
Engineered for heavy payloads and continuous, grueling operation. These heavy-duty brushless motors deliver exceptional thrust, maximum energy efficiency, and fade-free reliability across thousands of flight hours.
Classic Lightweight Truss Structure
Engineered for superior durability and minimal weight. This classic truss design maximizes structural integrity, providing a stable platform for spraying missions.
Advanced Fluid Dynamics Tank
Redefine your spray quality. This brand-new tank design features optimized fluid paths to work seamlessly with double-centrifugal nozzles, ensuring even coverage from leaf face to back.
All-Weather IP-Rated Casing
Protect your critical electronics from water and dust. This rugged, industrial-grade enclosure ensures operational reliability in any tough environment.
Route Planning
Drone route planning operates in three modes: Plot, Sweep, and Fruiter.
360° High-Flow Spreading System
The umbrella-shaped metal structure provides a wider force distribution area, ensuring uniform and clog-free material flow. The bottom spinner is embedded with a reinforced metal wheel, delivering superior pressure and wear resistance for extreme agricultural operations.
Technical Specifications
Technical Specifications
Technical Specifications
| Type | Quadcopter |
| Material | Aviation-grade carbon fiber |
| Diagonal Wheelbase | 1480 mm |
| Dimensions (Unfolded) | 1225 × 1055 × 585 mm |
| Dimensions (Folded) | 875 × 525 ×585 mm |
| Empty Weight (Without Battery) | 16 kg |
| Max. Takeoff Weight4 | 42 kg |
| Operating Speed | 5-10 m/s |
| Hovering Time (No Payload) | 20 min |
| Hovering Time (Full Payload) | 10 min |
| Flight Radius | s5km |
| Altitude Limit | 4500m |
| Wind Resistance | Level 7 |
| Max. Payload (Tank Capacity) | 16 L |
| Max. Spray Rate | 8 L/min |
| Effective Spray Width | 5-8 m |
| Operational Efficiency | Approx. 6.6 acres/hour (2.7 hectares/hour) |
| Multi-Mission Payload Rack | Quick-release and storage structure |
| Power System | Polymer lithium battery |
| Power Source (Battery Capacity) | 18,000 mAh |
| Operating Voltage | 58.8 V |
| Engine & Frame Lifespan | 5,000 hours, Frame: ≥8 years |
| Hovering & Flight Modes | Omni-directional hovering; Manual, intelligent, and Automatic modes |
| Advanced Navigation | Auto Altitude, Positition Hold, Return, AB Point Memory, Autonomous Planning |
| Night Flight | Supported |
| Safety & Recording | Dual-redundancy sensors; Electronic fencing; Flight data recorder |
*The parameters above are theoretical values, based on tests conducted under ideal conditions. Actual operation may result in deviations due to varying circumstances, so please rely on real-world testing data for accuracy.
Technical Specifications
Packaging Specifications
- Drone Color:
(3 colors available) - Package Type:
Export Standard Carton (Double-wall) - Package Dimensions:
985 × 590 × 610 mm - Volume (CBM):
0.355 m³ - Gross Weight:
16 kg - What’s Included:
1x Drone, 1x Tank, 2x Batteries, 1x Charger, Toolkit
Professional Technical Support
Committed to exceptional customer service, we provide comprehensive flight training, maintenance, and 24/7 online support to ensure effective and secure operations. Our expert team offers remote guidance, software updates, and both online and on-site technical support for your needs.
Expert After-Sales Support
Our professional technician team is 7×24 available for both online and on-site technical support.
Comprehensive Flight Training
Our complete drone flight training ensures you’re ready for operation with confidence and skill.
Accessible Resources
Benefit from well-documented support materials and instructional videos for easy learning and troubleshooting.
Local Support Network
Immediate aid through our trained global distributor network for prompt resolution of technical concerns.
